IP Relay Adaptor for the IX Series with 4 Contact Inputs / 10 Relay Outputs
BRAND
Aiphone
SES #
AIP IXWMA
MFG #
IXW-MA
UPC
No UPC Set
Your Price
Usually ships between 3-7 business days
The IXW-MA is a multi-purpose adaptor for the IX Series with 4 contact inputs and 10 relay outputs. The inputs on the IXW-MA can be used to send a command to a specific station to perform a task. The IXW-MA relays are associated to a specific station and programmed to change state when relay output 1 or 2 on the associated station changes state. The IXW-MA is a PoE device, and can be programmed via IX Series Support Tool 5.0 or later.
- New features available for North America with a firmware update
- Program using the IX Series Support tool
- Powered over POE, no additional power supply required!
- 4 activation inputs, 10 relay outputs
- Line Supervision events from IX Series master can trigger a relay closure
- Activate with either relay output from IX series stations
Power Source
802.3af PoE compliant
Power Draw
Standby: 43 mA; Maximum: 135 mA
Relay Output
Relays 1-4: Form C 24V AC/DC 500mA Relays 5-10: Form A 24V AC/DC 500mA
LAN
Ethernet (10BASE-T, 100BASE-TX)
Protocols
IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
Encryption system
TLS1.0, TLS1.1, TLS1.2
Port Security
IEEE 802.1X
Operating Temp
14° ~ 104°F (-10° ~ 50°C)
Dimensions
7-1/2" x 9-5/8" x 13/16"
Weight
1.39 lbs
