10 x 8 Combo Module RJ45 with RJ31X
BRAND
On-Q (Legrand)
SES #
ONQ CO1045
MFG #
CO1045
UPC
804428066897
Your Price
Usually ships between 3-7 business days
The 10x8 combo distributes up to 4 incoming telephone lines (RJ45) to 10 locations, and 1 GHz video to eight locations. The innovative mounting bracket includes a detachable platform for the coax splitter, allowing easy access to all termination ports during installation. The platform attaches securely to create a compact form factor that takes up minimal space in the enclosure.
- Eight way, 1 GHz passive digital HDTV cable splitter
- Coaxial splitter is compatible with existing and future networks such as VoIP and DOCSIS 3.0
- 10 way, 4-line RJ45 telecom module
- Includes RJ31X line seizure port for security installations
- Mounting infrastructure included
- UL Listed
Cable Type
Cat 5, Cat 5e, Cat 6, Coaxial
Color
Black
Connection Type
RJ45, F Connector, RJ31X
Type
Telecom/Video Module
Surge Protected
Splitter
UL Standard
Yes
UN SPSC
43222819
Height (Metric)
12.7 cm
Height (US)
5"
Length (Metric)
7.9 cm
Length (US)
3.1"
Width (Metric)
15.2 cm
Width (US)
6 in
Product Weight (US)
1.485 pounds
Frequency
5 MHz-1002 MHz
Material
18 Gauge Cold Rolled Steel
Mounting
Enclosure
OhmValue
Splitter
Operating Temperature (Celsius)
-40°C to 60°C
Receptacle Type
RJ45(10), F Connector(8), RJ31X(1)
Number Of Receptacles
19
