ELECTRIC LATCH RETRACTION KIT FALCON

BRAND
SDC (Security Door Controls)
SES #
SDC LR100FAK
MFG #
LR100FAK
UPC
No UPC Set

Your Price

Usually ships between 3-7 business days

The SDC LR100 Series Electric Latch Retraction Kit enables electric access control and dogging of mechanical exit devices. When energized the motor retracts the exit device latch and pulls the pushpad into the dogged (depressed) position enabling momentary or sustained push and pull operation of the door. The latch retraction mechanism may be activated by an access control, remote control device or building automation system. The exit device always provides uninhibited egress.
  • Opening for 36"
  • Models
    • Rim Mount 1790
    • Concealed Vertical Rod 1690
  • 1A Inrush, 200 mA Continuous @ 24VDC
  • For access control and sustained dogging applications
  • Simultaneous latch retraction and dogging (pushpad depressed) for most exit devices*
  • Pushpad is depressed* electrically for quieter push / pull operation
  • Automatic re-trigger if device does not pull on first try
  • Eliminates need for costly replacement of existing exit device
  • Significantly less labor and costs compared to competitive retrofit kits
  • Low current enables longer wire runs with smaller gauge wire
  • No door sequencers required for pairs of manual doors
  • Installs in Von Duprin non-free rated panic device without removing from the door
