G40005-38A 18/2 FPLP SOL BK N/S 1000' Black
BRAND
Southwire
MFG #
G40005-38A
SES #
SIG 81802-06-08
UPC
032886889523
Your Price
Usually ships between 3-7 business days
Southwire's Fire Alarm Cables are manufactured in accordance to the most crucial fire saftey codes and regulations, providing solutions for even the most critical of applications. These cables are superior for fire protective signaling circuits, as well as smoke detectors, voice communications, audio, control, initiating and notification circuits.
75°C 300V PLENUM RATED
STOCK #
G40005-38A
NO. OF CONDUCTORS
2
SIZE (AWG OR KCMIL)
18 AWG
NO. OF STRANDS
1
NOM. OD (MILS)
144 mils
NOMINAL TOTAL WEIGHT (LBS/1000')
16lbs/1000'
CONDUCTORS
18 AWG SOLID BARE COPPER
Insulation:
LS-PVC COLORS: BLACK, RED
Shield/Drain
UNSHIELDED
Jacket
LS-PVC, 2 CONDUCTORS, TWISTED AND JACKETED
RIPCORD
YES
MARKER TAPE
NO
UL 1424 FPLP, NEC article 760
UL 13 CL3P, NEC article 725; UL 444 CMP, NEC article 800; NFPA 262 (UL 910) / CSA FT6; CSA C22.2 CMG; RoHS (European Directive 22/95/EC)
