Signamax KJ458MT-C6C-GN MT-Series CAT6 Keystone Jack - T568A/B Wiring - Green

BRAND
Signamax
MFG #
KJ458MT-C6C-GN
SES #
SMX KJ458MT-C6C-GN
UPC
763474166756

Your Price

Usually ships between 3-7 business days

Introducing the Signamax KJ458MT-C6C-GN MT-Series CAT6 Keystone Jack, designed for high-density applications with its sleek slim profile. This keystone jack enhances wire retention and simplifies termination thanks to its rear 110 type contacts. It complies with IEC 60603-7 standards and supports various PoE applications, including IEEE 802.3af, 802.3at, and IEEE 802.3bt types 3 and 4. Compatible with Signamax's snap-in patch panels and work area faceplates, this kit includes circuit identification icons, dust covers, and 110 protection caps. Available in packs of 25 or master packs of 500, it exceeds TIA-568-C.3 performance specifications. Upgrade your network setup today with this reliable keystone jack!

  • Slim profile for the highest density applications
  • Improved wire retention and ease of termination with rear 110 type contacts
  • Meets IEC 60603-7, Supports IEEE 802.3af, 802.3at and IEEE 802.3bt type 3 and 4 PoE applications
  • Compatible with Signamax screened snap-in patch panels and work area faceplates
  • Circuit identification icons, dust covers and 110 protection caps included in kit
  • Available in convenient pack of 25 and master pack of 500 jacks
  • Exceeds TIA-568-C.3 component performance specifications
TRANSMISSION PERFORMANCE
ANSI/TIA-568-C.2: meets or exceeds category 6 (1-250 MHz) component specifications
TRANSMISSION MEDIA
Unscreened twisted pair (U/UTP)
JACK TYPE
8p8c (8-position, 8-contact) “RJ45" style
WIRING SCHEME
ANSI/TIA-568-C.2: T568A & T568BISO/IEC 11801 2nd Ed.: 8-position pin/pair assignment (1-2/3-6/4-5/7-8)
WIRE GAUGE
22 to 24 AWG (0.644 to 0.511 mm)
ELECTRICAL
Insulation Resistance: Min 500 MOhm @ 100 VdcDielectric Withstanding Voltage: 1,000 Vdc/ac peak contact-to-contact @ 60 Hz for 1 minSpring Wire Contact Resistance: Max 20 mOhmIDC Contact Resistance: Max 2.5 mOhmCurrent Rating: Refer to downloadable spec sheet.
CONSTRUCTION
Housing: High impact thermoplastic, UL94V-0 fire retardantJack Spring Wire: Phosphor bronze alloy plated with 50 μin of gold over 70 to 100 μin of nickelIDC: 110 type, phosphor bronze alloy with 100 μin 100% tin alloy
MECHANICAL
Total Contact Force: Min 800 g for 8 wire leadsRetention: 50 N (11 lbf) for 60 ± 5 sMating Cycle Life: Min 750 cycles
FOOTPRINT
Standard keystone footprint
MOUNTING DIMENSIONS:
1.18" D x 0.67" W x 0.76" H (30.0 mm x 16.9 mm x 19.3 mm)
ENVIRONMENTAL CONDITIONS
Operating Temperature: 14 °F to 140 °F (-10 °C to 60 °C)Storage Temperature: -40 °F to 158 °F (-40 °C to 70 °C)Operating RH: 93% Max (non-condensing)
COMPLIANCE
ANSI/TIA-568-C.2, IEEE 802.3 ab, FCC Part 68 Subpart F, UL 94V-0
APPLICATIONS
X.21, V.11, S0, ISDN, CSMA/CD 10BASE-T, 100BASE-TX, 100BASE-T4, 100BASE-T2, 1000BASE-T, 10GBASE-T, TR 4/16/100, 100BASE-VG, ATM LAN 25/51/155, TP-PMD
WARRANTY
5-year Limited Component10-year Signamax Base Trunk15-year Signamax Extended Component25-year Signamax Cabling System
