RCI YD30 Series Electronic Locks – a True Alternative to Maglocks

The RCI YD30 series of self-aligning locks by dormakaba are solving access control issues that have plagued the industry for years. These motor-driven electronic self-aligning locks are engineered to accommodate single and double acting doors and are particularly adept at addressing common challenges such as door misalignment and locks binding due to side load pressure.

Key Features and Benefits

Self-Aligning Mechanism: The YD30 locks can correct door misalignments up to 5/16". For example, they can compensate for doors that are not square or affected by negative pressure, which might otherwise keep the door from closing securely. The pivot action of the bolt pin can adjust for these misalignments effectively pulling the door into the correct position and securing it.

Side Load Release Capability: For anyone new to the term “side load,” this refers to the amount of force or pressure that is applied to a locking mechanism from the side, rather than directly in line with the lock. When a lock is installed, it is designed to withstand a certain amount of force. But, if a force is applied to the lock from the side in a consistent manner, this can create side load, which can cause damage to the lock or cause a lock to jam completely, which can keep a door from being opened.

The YD30 locks are designed to release promptly upon request, even under substantial side load pressure. They can handle loads exceeding 1,322 lbs (600 kg) and still disengage, enhancing safety and reliability in high-traffic areas.

High Security: Security is paramount with the YD30 series. The locks feature automatic deadbolting with a robust 10mm thick stainless steel bolt pin, offering a holding force of up to 2,204 lbs (1,000 kg). This helps to prevent unauthorized entry.

Versatile Installation Options: The YD30 series offers flexibility in installation, accommodating both surface and mortise mounting. This versatility makes them suitable for a wide range of door types such as wood, metal, and even glass, which in many cases means electronically securing a door without compromising the 180° swing.

Fail-Safe and Fail-Secure Configurations: While the largest majority of applications will require these locks to operate in fail-safe mode, users can easily switch between fail-safe and fail-secure modes by adjusting a single DIP switch. This adaptability allows the locks to meet operational preferences or specific security requirements required by code or the authority having jurisdiction.

Efficient Power Consumption: Designed for low voltage operation, the YD30 locks function within a 12-24 VDC range and consume minimal standby current (<50mA at 12VDC or 25mA at 24VDC). This efficiency makes them suitable for continuous operation in various environments. Studies have shown that the YD30 locks utilize 95% less energy than a standard magnetic lock.

Ideal applications for the YD30 include:

Commercial Buildings: Ensuring secure access to offices, conference rooms, data centers, and restricted areas even where maintaining low energy is critical.

Healthcare Facilities: Providing reliable security for sensitive areas while accommodating high traffic.
Airports and Government Buildings: Meeting stringent security requirements with robust locking mechanisms.

RCI YD30 locks by dormakaba combine advanced technology with practical features to finally address challenges that access control professionals have been struggling to solve for decades. The unique features of the YD30 locks outlined above make them a reliable choice for a wide range of applications, ensuring both security and convenience.
